MIL-DTL-50911B
Drawing Number
8861119
4.4.2.3
Booster assembly
Next Higher
Assembly
9219074
Inspection
Classification
Examination or Test
Conformance
Requirement
Method /
Criteria
Paragraph
Reference
Critical
1
Booster cups split or cracked, exposed
100%
3.8
Visual
charge, evidence of explosive leakage
Major
101
Charge missing
Level IV
3.3
Gage
102
Outside diameter, max
Level IV
3.3
Gage
103
Depth to charge, min
Level IV
3.3
Gage
104
Weight of charge
1/
3.5
4.5.2
Minor
201
Marking missing, incorrect, or identifiable
Level II
3.3
Visual
202
Workmanship
Level II
3.8
Visual
Note: 1/ Total of 32 samples.
Drawing Number
4.4.2.4
Priming assembly
9219074
Next Higher
Assembly
Inspection
Classification
Examination or Test
Conformance
Requirement
Method
Criteria
Paragraph
Reference
Critical
1
Booster cups split or cracked, exposed
100%
3.8
Visual
charge, evidence of explosive leakage
Major
101
Length, max
Level IV
3.3
Gage
102
Double crimp missing or incorrect
Level IV
3.3
Visual
103
Booster assemblies (2) improperly
Level IV
3.3
Visual
assembled or missing
104
Detonating cord clips (2) improperly
Level IV
3.3
Visual
assembled, damaged, missing, or not
secure to detonating fuse
105
Output
1/
3.6
4.5.3
Minor
201
Workmanship
Level II
3.8
Visual
Note: 1/ Total of 3 samples.
