MIL-DTL-13139F
Drawing number
4.3.2.7
Cone
8861579
Next higher assembly
9230162
Conformance
Requirement
Paragraph reference/ inspection
Category
Examination or test
criteria
paragraph
method
Critical
None defined
Major
101
Concentricity of large outside diameter
IV
3.4
Gage
with basic diameters
102
Location of large basic diameter
IV
3.4
Gage
103
Excessive wall thickness variation
IV
3.4
Gage
104
Material improper for type
IV
3.4
Visual/Manual
105
Location of small basic diameter
IV
3.4
Gage
106
Annealing of cone
100%
3.9
Gage, 4.3.3.6
107
Heat shock test of cone
IV
3.10
4.3.3.7
Minor
201
Large outside diameter, max.
II
3.4
Gage
202
Total height, max.
II
3.4
Gage
203
Evidence of poor workmanship
II
3.11
Visual
13
