MIL-DTL-13139 Charge, Demolition, Shaped, 15 Lb.-M2A4 Parts ForThis specification covers the parts for one type of demolition item designated as Charge, Demolition, Shaped, 15 lb.-M2A4.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20


MIL-DTL-13139F
Drawing number
4.3.2.9
Container, cone
8861570
Next higher assembly
9230162
Conformance
Requirement
Paragraph reference/ inspection
Category
Examination or test
criteria
paragraph
method
Critical
None defined
Major
101
Location of upper basic diameter
IV
3.4
Gage
102
Concentricity of small inside diameter
IV
3.4
Gage
with basic diameter
103
Large inside diameter
IV
3.4
Gage
104
Location of lower basic diameter
IV
3.4
Gage
Minor
201
Evidence of poor workmanship
II
3.11
Visual
15
