MIL-DTL-13139F
Table II. First article inspection
Conformance
Requirement
Paragraph reference/
Examination or test
criteria
paragraph
inspection method
Dwgs.8861579/9230162 and
all referenced drawings
Material (see Note 1)
10
3.3
therein
4.3.3.5
Parts and Sub-assemblies
3.4
10
4.3.2
(see Note 2)
Leakproofness of body
assembly and closing cap
10
3.5/3.6
4.3.3.1/4.3.3.2
assembly
Fit of closing cap assembly
10
3.7
4.3.3.3
Fit of stand-off sleeve
10
3.8
4.3.3.4
Annealing of glass cone
10
3.9
4.3.3.6
Heat shock test of glass cone
10
3.10
4.3.3.7
Workmanship
10
3.11
Visual
Note 1: Certificate of analysis shall be provided for all materials.
Note 2: 100% inspection of all drawing characteristics shall be performed.
4.3 Conformance Inspection.
4.3.1 Inspection lot formation. Each lot of shaped charges shall contain:
a. Body assemblies from not more than one lot interfix number from one manufacturer.
b. Glass cones from not more than one batch from one manufacturer.
4.3.2 Examination. Unless otherwise specified in the Conformance Inspection, sampling
plans for major and minor defects shall be in accordance with MIL-STD-1916, Verification
Level IV for Major defects and Verification Level II for Minor defects.
