MIL-DTL-17124F
TABLE III. First article tests and inspections for Type III.
Examination or test
Drawing
Sample Requirement
Verification
size
paragraph
Dummy Cord, Detonating
13042072
Construction
5/1&2
Diameter
3.2
4.8
/1&2
Outer color
5
3.2
Visual (general match)
/1&2
Smooth exterior
5
3.2
Visual
/1&2
Finish/outer construction
5
3.2
Visual
/1&2
Inner construction
5
3.2
Visual/manual
/1&2
Weight of finished cord
5
3.2
4.9
/1&2
Color on inert fill
5
3.2
Visual (general match)
/1&2
Weight of inert fill
5
3.2
4.11
/1
Breaking strength
5
3.2
4.10
/1
Flexibility
5
3.11
4.21
/1
Ammunition lot numbering
5
3.12
Visual
/1
Workmanship
5
3.13
Visual
Notes:
/1
A total of five (5) spools shall be randomly selected for first article inspection. From each of the
spools, cut a random set of samples for inspection and testing.
/2
Randomly cut one (1) sample, not less than eighteen (18) inches long, from each of the five (5) spools
and sequentially subject them to the specified tests.
4.3 Conformance inspection. Conformance inspection shall be performed in
accordance with 4.3.2 through 4.3.4.2.
4.3.1 Conformance sampling. For each lot, a total of five (5) spools shall be
randomly selected. The number of samples per spool shall be in accordance with 4.3.2
through 4.3.4.2. Samples shall be cut from each of these spools and then subjected to the
specified tests.
4.3.2 Conformance rejection. If any assembly, component or test specimen fails to
comply with the requirements, the lot from which the sample was taken shall be rejected.
4.3.3 Inspection lot formation. Inspection lots shall conform to the requirements of
MIL-STD-1916. In addition inspection lots shall contain materials from not more than one
lot interfix number from one manufacturer.
4.3.4 Inspection requirements by classification of characteristics.
a. For the conformance inspection paragraphs 4.3.4.1 through 4.3.4.2, the
definitions of critical, major and minor defects are provided in paragraph "Definitions" of
MIL-STD-1916.
b. The acceptance criteria for sampling inspection shall be in accordance
with the levels provided in conformance examination/test paragraph and MIL-STD-1916.
6
