MIL-DTL-417H
4.2.2 PCA rejection. If any item of the sample fails to comply with the PCA
requirements, the sample shall be rejected.
4.3 First article. When specified, a sample shall be subjected to first article verification.
4.3.1 First article quantity. First article inspection shall be performed on the quantities
listed in Table II.
4.3.2 First article rejection. If any item of the sample fails to comply with the first article
requirements, the sample shall be rejected.
TABLE II. First article tests and inspection.
Paragraph
Reference /
Drawing
Sample
Requirement
Examination or Test
Inspection
Number
Size
Paragraph
Method
Priming adapter.
13021902
Examination of defects
1/
3.2.1
4.4.3.1
Note:
1/ If one cavity is used to mold the Adapter, a minimum of ten (10) samples shall be subjected to
first article tests and inspection. If more than one cavity is used to mold the Adapter, a minimum of
five (5) samples from each cavity that is used to mold the Adapters shall be subjected to first article
tests and inspection. Each Adapter shall be traceable to the cavity in which it was molded.
4.4 Conformance. Conformance inspection shall be performed in accordance with
4.4.3.1.
4.4.1 Conformance rejection. If any assembly, component or test specimen fails to
comply, the lot from which the sample was taken shall be rejected.
4.4.2 Lot formation. Lot formation shall be in accordance with the lot formation
requirements of MIL-STD-1916.
4.4.3 Classification of characteristics.
a. For the conformance inspection paragraph 4.4.3.1, the definitions of critical,
major and minor defects are provided in paragraph "Definitions" of MIL-STD-1916.
b. Inspection sampling requirements for critical, major and minor characteristics
are defined in MIL-STD-1916. Unless specified otherwise, Verification Level VII in addition to
100% inspection shall be used for all characteristics defined as Critical, Verification Level IV
shall be used for all characteristics defined as Majors and Verification Level II for all Minor
characteristics.
c. Alternative conformance acceptance. Alternate conformance procedures may
be proposed (See paragraph "Acceptance by contractor-proposed provisions" of MIL-STD-
1916).
4
