MIL-DTL-417H
Drawing Number
13021902
4.4.3.1
Priming adapter.
Next Higher
Assembly
Inspection
Classification
Examination or Test
Conformance
Requirement
Method /
Criteria
Paragraph
Reference
Critical
None defined
Major
101
Pitch diameter of thread
Level IV
3.2.1
Gage
102
Major diameter of thread
Level IV
3.2.1
Gage
103
Minor diameter of thread, maximum
Level IV
3.2.1
Gage
(max)
104
Depth of counterbore, max.
Level IV
3.2.1
Gage
105
Diameter (0.300) of counterbore, min.
Level IV
3.2.1
Gage
106
Perpendicularity
Level IV
3.2.1
Gage
107
Concentricity
Level IV
3.2.1
Gage
108
True position of countersink
Level IV
3.2.1
Gage
109
Slot obstructed or missing
Level IV
3.2.1
Visual
Minor
201
Width across flats
Level II
3.2.1
Gage
202
Total length
Level II
3.2.1
Gage
203
Diameter of countersink
Level II
3.2.1
Gage
204
Length of flats
Level II
3.2.1
Gage
205
Width of slot, max.
Level II
3.2.1
Gage
206
Color
Level II
3.2.1
Visual
207
Workmanship
Level II
3.3
4.6
4.5 Ammunition lot number. Visually verify that an ammunition lot number has been
assigned to each lot as described in MIL-STD-1168.
4.6 Workmanship. All parts and assemblies shall be verified by visual inspection.
Evidence of said workmanship defects shall be cause for lot rejection.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as
specified in the contract or order (see 6.2). When packaging of materiel is to be performed by
DoD or in-house contractor personnel, these personnel need to contact the responsible packaging
activity to ascertain packaging requirements. Packaging requirements are maintained by the
Inventory Control Point's packaging activities within the Military Service or Defense Agency, or
within the military service's system commands. Packaging data retrieval is available from the
managing Military Department's or Defense Agency's automated packaging files, CD-ROM
products, or by contacting the responsible packaging activity.
5
