MIL-DTL-45144E
TABLE III. First article tests and inspections (Type II)
EXAMINATION OR TEST
DRAWING
SAMPLE
REQUIREMENT
VERIFICATION
NUMBER
SIZE
PARAGRAPH
Dummy Fuse, Blasting,
N/A
80
3.4 through 3.8.4/
4.3.3.3/4.3.3.4
Time, Inert
3.8.6 through 3.12/
3.14
Box, Fiberboard,
9242366
10
5.2.1
4.3.3.10
Ammunition, For Fuse,
Blasting, Time, M700
Box, Packing,
9242367
10
5.2.2
4.3.3.13 /
Ammunition, For Dummy
4.3.3.14
Fuse, Blasting, Time, Inert
Pallet
N/A
MIL-P-
5.2.41
4.3.3.16
15011
Unit load
19-48-
1
5.2.4.2
4.3.3.16
4116/130A
4.2.1. First article rejection. If any assembly, component or test specimen fails to comply, the
sample shall be rejected.
4.3. Conformance inspection. Conformance samples shall be randomly drawn during
production. Conformance inspection shall be performed in accordance with 4.3.3.1 through
4.3.3.16.
4.3.1. Conformance rejection. If any assembly, component or test specimen fails to comply,
the lot from which the sample was taken shall be rejected.
4.3.2. Lot formation. The lots shall conform to the requirements of MIL-STD-1916 and the
lot number shall be in accordance with MIL-STD-1168. In addition lots shall contain:
a. Fuse powder components from not more than one lot interfix number from one
manufacturer.
b. Materials from not more than of one lot interfix number from one manufacturer.
4.3.3. Classification of characteristics.
a. Sampling requirements. Inspection sampling requirements for critical, major and
minor characteristics are defined in MIL-STD-1916. Unless specified otherwise, Inspection Level
VII shall be used for all characteristics defined as Critical, Inspection Level IV shall be used for all
characteristics defined as Majors and Inspection Level II for all Minor characteristics.
b. Inspection. Conformance inspection shall be performed in accordance with
4.3.3.1 through 4.3.3.16 using the applicable attribute sampling plans. For all conformance
inspections the same specimen may be used for all non-destructive examinations or tests.
11
