MIL-DTL-2156 Charge, Demolition, Shaped, 15 Lb. - M2A4 Loading, Assembling And PackingThis specification covers the loading, assembling and packing for one type of demolition kit designated as Charge, Demolition, Shaped, 15lb. - M2A4.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23


MIL-DTL-2156D
Drawing number
4.3.2.1
Booster
8858393
Next higher assembly
8861565
Conformance
Requirement
Paragraph reference/
Category
Examination or test
criteria
paragraph
inspection method
Critical
None defined
Major
Concentricity of small cavity to outside
101
IV
3.3
Gage
diameter
102
Diameter of small cavity, minimum (min.)
IV
3.3
Gage
103
Depth of Large cavity, min.
IV
3.3
Gage
104
Specific gravity
5
3.3
4.3.3.1
Minor
201
Depth of small cavity, min.
II
3.3
Gage
202
Diameter of large cavity, min.
II
3.3
Gage
203
Total length, maximum (max.)
II
3.3
Gage
204
Radius missing
II
3.3
Visual
205
Evidence of poor workmanship
II
3.6
Visual
7
