MIL-DTL-46550D(AR)
Conformance Inspection
MIL-DTL-46550
CLASSIFICATION OF CHARACTERISTICS
TITLE
PARAGRAPH
DRAWING NUMBER
8858394
4.3.2.5
Closing cap assembly
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
CATEGORY
EXAMINATION OR TEST
NO. OF
VERIFICATION
REQUIREMENT
PARAGRAPH REFERENCE/
SAMPLE
LEVEL
PARAGRAPH
INSPECTION METHOD
UNITS
Critical
None defined
Major
101
Concentricity of inside diameter of closing
IV
3.3
Gage
cap to thread
102
Dent in thread or detonator cavity
IV
3.3
Visual
103
Tape missing, loose, or mislocated
IV
3.3
Visual
104
Enamel paint or color improper
IV
3.3
Visual
Minor
201
Length and diameter of cavity inside
II
3.3
Gage
202
Paint in detonator well
II
3.3
Visual
203
Protective coating missing, inadequate, or
Visual
II
3.3
improper
204
Evidence of poor workmanship
II
3.6
Visual
