MIL-DTL-46550 Charge, Demolition, Shaped, 40 Lb. M3A1, Metal Parts AssemblyThis specification covers the parts and assemblies for one type of demolition kit designated as Charge, Demolition, Shaped, 40 lb., M3A1.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22


MIL-DTL-46550D(AR)
Conformance Inspection
MIL-DTL-46550
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8858401
4.3.2.9
Stand-off frame assembly
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
CATEGORY
EXAMINATION OR TEST
NO. OF
VERIFICATION
REQUIREMENT
PARAGRAPH REFERENCE/
SAMPLE
LEVEL
PARAGRAPH
INSPECTION METHOD
UNITS
Critical
None defined
Major
101
Total length, max.
IV
3.3
Gage
102
Thumb screw missing
IV
3.3
Visual
Minor
201
Color coding improper
II
3.3
Visual
202
Protective coating missing or inadequate
II
3.3
Visual
203
Evidence of poor workmanship
II
3.6
Visual
16
