MIL-DTL-46550D(AR)
Conformance Inspection
MIL-DTL-46550
CLASSIFICATION OF CHARACTERISTICS
TITLE
PARAGRAPH
DRAWING NUMBER
8858399
4.3.2.1
Well detonator
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
8858397
NO. OF
VERIFICATION
REQUIREMENT
PARAGRAPH REFERENCE/
CATEGORY
EXAMINATION OR TEST
SAMPLE
LEVEL
PARAGRAPH
INSPECTION METHOD
UNITS
Critical
None defined
Major
101
Diameter and length of cavity
IV
3.2
Gage
102
Outside diameter of body, maximum (max.)
IV
3.2
Gage
103
Wall thickness, minimum (min.)
IV
3.2
Gage
Minor
201
Diameter of flange, max.
II
3.2
Gage
202
Thickness of flange, max.
II
3.2
Gage
203
Length of closed end, max.
II
3.2
Gage
204
Evidence of poor workmanship
II
3.6
Visual
8
