MIL-DTL-45468F(AR)
4.3.2.9
Unitization.
DRAWING NUMBER
19-48-4116/121Q
NEXT HIGHER ASSEMBLY
-------------------
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
PARAGRAPH REFERENCE/
CATEGORY
CRITERIA
PARAGRAPH
INSPECTION METHOD
Critical
None defined
Major
101
Pallet not in accordance with
See 1/
3.3
See 1/
requirements
102
Pallet markings missing, incorrect or
IV
3.3
Visual
not located properly
103
Boxes incorrectly oriented or
IV
3.3
Visual
positioned on pallet
104
Filler assembly, if required, not
IV
3.3
Visual
made, treated, or marked correctly
105
Strapping incorrectly routed, not
IV
3.3
Visual
located correctly or material
incorrect
106
Unit load not tightly strapped or any
IV
3.3
Visual
strap loose
107
Strapping seal not properly crimped
IV
3.3
Visual
108
Wood preservative marking is
IV
3.3
Visual
missing, incorrect, or in incorrect
location on pallet.
109
Heat treatment stamp missing,
IV
3.3
Visual
incorrect, or in incorrect location on
pallet.
Minor
201
Evidence of poor workmanship
II
3.11
Visual
1/: Inspection shall be in accordance with MIL-P-15011 except MIL-STD-1916 shall be used in lieu of MIL-STD-105.
4.3.3 Moisture content of lead azide. The moisture content of the lead azide shall be
determined for each lot at the time of loading. A sample shall be selected from that quantity of
lead azide used in each production shift, and tested as specified in 4.3.3.1. A composite sample
shall not be used. If the moisture content is in excess of the percentage specified and loading has
not begun, the lot of lead azide shall be rejected until proper corrective action has been
accomplished as verified by performing the moisture content test specified in 4.3.3.1. If loading
has begun, action on the unloaded lead azide shall be as specified above and all components
loaded with the nonconforming lead azide shall be rejected.
4.3.3.1 Determination of moisture content of lead azide. The moisture content of the
lead azide shall be determined in accordance with Method 101.5 of MIL-STD-650, except that a
two-gram (gr.) sample shall be tested and the dish shall be covered with a sheet of
polytetrafluoroethylene.
12
