MIL-DTL-45468F(AR)
4.3.2.5
Assembly (prior to insertion in spool).
DRAWING NUMBER
8830972
NEXT HIGHER ASSEMBLY
-------------------
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
PARAGRAPH REFERENCE/
CATEGORY
CRITERIA
PARAGRAPH
INSPECTION METHOD
Critical
1
Cup split or cracked or explosive
100% + VL-VII
3.3
Visual
leakage
2
No-fire test
100% + VL-VII
3.7
4.3.6
3
Lead wires not shunted
100% + VL-VII
3.3
Visual
Major
101
Length of cup, max.
IV
3.3
Gage
102
Diameter of cup, crimp end, max.
IV
3.3
Gage
103
Insulation on lead wires damaged
IV
3.3
Visual
104
Not crimped 360° (4 places)
IV
3.3
Visual
105
Moisture content of lead azide
2 grams, see 1/
3.4
4.3.3
Minor
201
Evidence of poor workmanship
II
3.11
Visual
1/: Sampling of lead azide shall be in accordance with 4.3.3.
DRAWING NUMBER
Assembly.
4.3.2.6
8830972
NEXT HIGHER ASSEMBLY
-------------------
EXAMINATION OR TEST
REQUIREMENT
PARAGRAPH REFERENCE/
CONFORMANCE
CATEGORY
CRITERIA
PARAGRAPH
INSPECTION METHOD
Critical
None defined
Major
101
Insulation on wires damaged
IV
3.3
Visual
102
Spool torn or crushed
IV
3.3
Visual
103
Waterproofness
110
3.8
Figure 1 and 4.3.7
104
Functioning ampere
50
3.9.1
Figure 1 and 4.3.8.1
105
Functioning milliwatt-second
50
3.9.2
Figure 1 and 4.3.8.2
106
Functioning 50 cap series
50
3.9.3
Figure 1 and 4.3.8.3
107
Functioning 4 cap series
40
3.9.4
Figure 1 and 4.3.8.4
Minor
201
Wires improperly wrapped on spool
II
3.3
Visual
202
Evidence of poor workmanship
II
3.11
Visual
9
